Full Servo Functional Horizontal Cartoning Machine BMZX670G
| Place of Origin | CH |
|---|---|
| Brand Name | BM |
| Certification | CE |
| Model Number | BMZX670G |
| Minimum Order Quantity | 1 |
| Price | US$30000.00 - 60,000.00 |
| Packaging Details | PE Bag / Bubble Wrap/Plastic Blister /Molded Foam/ Corrugated Box/ Wooden Crate/Pallet |
| Delivery Time | 20-30 working days |
| Payment Terms | T/T |
| Supply Ability | 500 sets / year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Machine Type | Full Servo Full Auto | Product Type | Cartoning Machine |
|---|---|---|---|
| Designed Packing Speed | 5-10 Cartons/minute (depending On Product) | Length（mm） | 270-550mm |
| Width（mm） | 180-380mm | Height | 180-400mm |
| Sealing Method | Tape Sealing (48 Mm, 70 Mm Width Optional) | Machine Net Weight | Approx. 3000 Kg (including Material Handling Line) Main Unit Dimensions (mm) |
| Equipment Power (kW) | 10 KW (including Material Handling Line) | Power Supply Type | 380 V±10%, 50 Hz±5%, Control Voltage: DC 24 V |
| Dimensions | 6600*2550*2250mm(including Material Handling Line) | Machine Noise | ≤ 75dB(A) |
| Air Consumption | 200 L/minute (customer To Provide Air Supply) | Air Supply | 0.6～0.8 MPa |
| Carton Blank Material | Corrugated Cardboard Box | ||
| Highlight | 3000 kg automatic cartoning machine,3000 kg horizontal cartoning machine,full auto automatic cartoning machine |
||
Product Description
Full Servo Functional Horizontal Cartoning Machine BMZX670G
The BMZX670G Functional Horizontal Cartoning Machine features a compact structure, stable reliability, small footprint, convenient layout, and simple maintenance.
Key Features & Operation
- Automatic box feeding with shortage alarm or shutdown functionality
- Automatic material conveying stop during equipment malfunctions for easier troubleshooting
- Mechanical overload protection with automatic machine stop
- Servo control system automatically returns to phase after manual overload reset
- Robotic arm simplifies material handling operations
- Tape-based box sealing system ensures smooth and aesthetically pleasing seals
- Manual tape replacement required after machine shutdown
- Specific carton quality requirements for optimal performance
Competitive Advantages
- Compact footprint saves valuable production space
- Convenient changeover and specification adjustment capabilities
Customization & Service Capabilities
- Small-Batch Customization: MOQ starts from 1 unit, flexibly adaptable to various product specifications including household paper and food packaging bags. Modular design enables quick adjustments to packaging speed, size, and materials.
- Fast Delivery & Agile Response: Standardized components with localized supply chain ensure 15-35-day lead time. 24/7 technical support with on-site emergency service within 48 hours (priority for Asia, Africa, and Latin America).
- Specialization in Niche Markets: 20 years of expertise in household paper packaging, optimized for small-to-medium capacity. Continuous upgrades include auto-alignment systems and low-noise design (<65dB).
- Cost-Optimized Solutions: 30-40% more cost-effective than international brands with comparable performance, reducing ROI period to 6-12 months. Energy-efficient designs with servo motors reducing power consumption by 20%+.
- Quality Control & Certifications: Rigorous quality control from raw material inspection to 72-hour continuous load testing. International certifications include CE and ISO9001, compliant with EU, Middle Eastern, and Southeast Asian standards.
