Fully Automatic Cartoning Machine 8.75 Kw For Packaging Bottled And Bagged Products BMZH-200G
| Place of Origin | CH |
|---|---|
| Brand Name | BM |
| Certification | CE |
| Model Number | BMZH-200G |
| Minimum Order Quantity | 1 |
| Price | US$30,000.00 - 70,000.00 |
| Packaging Details | PE Bag / Bubble Wrap/Plastic Blister /Molded Foam/ Corrugated Box/ Wooden Crate/Pallet |
| Delivery Time | 20-30 working days |
| Payment Terms | T/T |
| Supply Ability | 500 sets / year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Machine Type | Full Servo Full Auto | Product Type | Cartoning Machine |
|---|---|---|---|
| Length（mm） | 120-250 Mm | Width（mm） | 45-180 Mm |
| Height（mm） | 30-100 Mm | Packaging Material | 250-350g/m2 |
| Gluing Method | Spray Glue / Pneumatic Rubber Lifting(to Be Ordered) | Rated Speed (P/min) | 30-70 Bags/min |
| Configuration | 6servos / Appearance Frosted Silver Carbon Steel | Gas Consumption | 96-120 L/min |
| Power Supply | (The Purchaser Is Responsible For Providing The Required External Power Cord):3-phase 380V 50Hz （3+N+P） | Equipment Dimensions (L X W X H) | 4290*1715*1580 Mm |
| Servo Motor Power | Approximately 4.15 KW | Net Weight | 850kg |
| Machine Noise | ≤ 70dB | Total Power (Hot Melt Glue Power Included) | 8.75 Kw |
| Highlight | automatic cartoning machine 8.75 kw,8.75 kw auto cartoning machine,380v auto cartoning machine |
||
Product Description
BMZH-200G Fully Automatic Cartoning Machine For Food, Daily Chemicals, Toys, And Cosmetics.
BMZH-200G Fully Servo Intelligent Cartoning Machine for packaging bottled and bagged products such as agricultural chemicals, daily chemical products, medical supplies, hardware products, and confectionery.
- This machine is primarily suitable for automatic cartoning of products in industries such as food, daily chemicals, toys, and cosmetics.
- It automatically completes a series of steps, including feeding, opening, inserting, and gluing and sealing. It delivers a high yield rate of finished products and beautiful seals, significantly improving efficiency and reducing labor costs.
- The entire machine utilizes 9 servo motors with independent control, feed detection, and gluing detection.
- The machine's sheet metal construction offers a sleek, aesthetically pleasing design and ease of operation.
- It utilizes a PLC controller for stable and reliable operation.
- The touchscreen displays real-time operating data, automatically memorizes recipes, and allows for easy switching between product storage options.
- It is compatible with a variety of paper box sizes and offers convenient adjustments. Optional auxiliary functions include gluing, coding, and stamping.
- The independent servo motor rotates the carton opener, ensuring stable opening and a high success rate. Multiple safety features and self-diagnostic functionality provide clear fault indication.
CUSTOMIZATION
- Expert in Small-Batch Customization - MOQ starts from 1 unit, flexibly adaptable to various product specifications (household paper, food packaging bags, etc.). Modular design enables quick adjustments to packaging speed, size, and materials.
- Fast Delivery & Agile Response - Standardized components with localized supply chain ensure 15-35-day lead time. 24/7 technical support with on-site emergency service within 48 hours (priority for Asia, Africa, and Latin America).
- Specialization in Niche Markets - 20 years of expertise in household paper packaging, optimized for small-to-medium capacity. Continuous upgrades include auto-alignment systems and low-noise design (<65dB).
- Cost-Optimized Solutions - 30-40% more cost-effective than international brands with comparable performance, reducing ROI period to 6-12 months. Energy-efficient designs (servo motors reduce power consumption by 20%+).
- Quality Control & Certifications - Rigorous quality control from raw material inspection to 72-hour continuous load testing. International certifications include CE and ISO9001, compliant with EU, Middle Eastern, and Southeast Asian standards.
